Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service

Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service

    • Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service
    • Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service
  • Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service

    Product Details:

    Place of Origin: China
    Brand Name: QIYAO
    Certification: ISO

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Customized Product, Quoted Case By Case
    Packaging Details: Seaworthy packing
    Delivery Time: 30 weeks subject project
    Payment Terms: T/T, L/C
    Supply Ability: 20 sets per year
    Contact Now
    Detailed Product Description
    Material: Stainless Steel, Carbon Steel Arrangement: Vertical Or Horizontal As Working Conditions
    Function: Decontamination Of Toxic & Harmful Gas Or Liquid Application: Refineries, Petrochemical, Chemical, Etc.
    Method Of Treatment: Thermal Oxidization Customized: Available
    Service: Design, Supply Of Equipment With Technical Supervision At Site Emission: Friendly & Minimized Emission Under Standard And Regulation
    High Light:

    regenerative thermal oxidizer

    ,

    rto thermal oxidizer

    Waste Gas Thermal Oxidizer (Incinerator)



    Capacity: 0~500,000Nm3/h

    Method of treatment: Thermal Oxidization

    Applications: Incineration treatment of various types of organic waste gas and VOCs exhausted from chemical plants, refineries and VOCs.



    Summary:

    Waste Gas Thermal Oxidizer is to handle the organic compositions contained in waste gas by means of thermal oxidization, which converts the compositions of C and H contained in the organics into the pollution-free compositions: CO2 and H2O. The temperature of incineration shall be controlled between 800-1100℃. The supply of fuel and combustion air subject to staging control so as to control the NOx discharged.

    For waste gas of diversified compositions and heat values, the treatment processes of the waste gas thermal oxidizer are of a certain difference, but in general, the system usually mainly consists of waste gas combustion system and waste heat recovery system.



    Advantages:

    1. High efficiency of treatment: The decomposition ratio of waste gas can be up to 99.999%;
    2. Customized process: Always the most suitable solution is provided for clients;
    3. Low NOx combustion technology: It is ensured that the emission can satisfy related emission standard;
    4. Highly modularized design;
    5. Flexible waste heat recovery method: The waste heat can be recovered to produce steam or preheat waste gas, heat transfer oil and etc.;
    6. Advanced design software: Temperature field and velocity field of the thermal oxidizer chamber is simulated with simulation software.



    Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service

    Waste Gas Thermal Oxidizer for decontamination of toxic & harmful gas and liquid with Turnkey Service
